| Processor (CPU) |
Supports 1 × CPU. Compatible CPUs: from Intel Xeon E‑2200 family (up to 8 cores), or lower‑end like Intel Core i3, Pentium, Celeron depending on configuration.
|
| Memory (RAM) |
4 × DDR4 UDIMM slots, ECC (registered or unregistered depending on module).
Official maximum supported RAM: 64 GB UDIMM at up to 2666 MT/s.
|
| Storage / Drive Bays |
Flexible storage configurations depending on needs:
• Up to 8 × 2.5″ hot‑plug SAS/SATA/SSD drives — good for high‑performance or SSD‑based storage.
• Or up to 4 × 3.5″ hot‑plug SAS/SATA drives — for larger‑capacity HDD‑based storage.
|
| Storage Controllers & Boot Options |
Internal RAID / storage controller options: e.g. PERC H330, PERC H730P, HBA330, or software RAID (PERC S140).
Boot‑optimized options: there’s support for M.2 drives via BOSS (Boot Optimized Storage Subsystem) — e.g. 2 × M.2 240 GB (RAID 1 or non‑RAID) or 1 × M.2 240 GB (non‑RAID), plus internal micro‑SD module in some configs.
|
| Expansion / I/O / PCIe Slots |
Comes with 2 × PCIe Gen3 slots (one x16 full-/half‑height slot, one x8 low‑profile slot) — usable for extra NICs, HBAs, storage/RAID cards, etc.
On‑board networking: 2 × 1 GbE LOM NIC ports standard.
|
| Power Supply |
Supports single or redundant hot‑plug power supplies, either 350 W (Platinum) or 550 W (Platinum) depending on config and load.
|
| Management & Security |
Integrated remote management through iDRAC9 (with remote console, lifecycle controller, firmware updates, monitoring) + support for remote management tools via the vendor’s management software suite.
Security features: cryptographically signed firmware, Secure Boot, optional TPM 1.2/2.0, “Silicon Root of Trust”, and “System Lockdown / Secure Erase” options.
|
| Form Factor & Physical Dimensions |
1U rack‑mount chassis. Typical dimensions: Width ~ 434.0 mm, Depth ~ 595–596 mm (depending on drive configuration). Weight ~ 13.6 kg |
